OLHLRH16
OLHLRH16 LED Hazardous Location Remote Head
The OLHLRH16 is a fiberglass-reinforced LED remote head rated for Class 1, Division 2, Groups A-D hazardous locations, available in single or twin-head configurations with IP66 and NEMA 4X ratings for demanding industrial and outdoor environments.
Inventory and Lead Time
Contact us for availability and pricing information.
Need assistance?
Call us at
(866) 471-7711
OLHLRH16 LED Hazardous Location Remote Head
OLHLRH16 LED Hazardous Location Remote Head
Contact for Pricing
Downloads & Resources
Product Overview
Features
- Housing is fiberglass reinforced construction in gray finish.
- Corrosion-resistant enclosure with one piece, high-impact resistant, UV stabilized polycarbonate lens and molded gasket with stainless steel screws.
Mounting
- Die-cast mounting brackets provided for surface wall-mount installation.
- Distance of maximum run is determined by system voltage, wire gauge and total maximum wattage on the run.
LED
- Two fully adjustable, ultra bright 3.3 watt high performance MR-16 base LED lamp heads for optimized center-to-center spacing.
Electrical
- Powered from low voltage 6V/12V DC power source with low voltage wiring (not provided).
Listing
- Five year warranty.
- UL listed.
- IP66 rated for Ingress protection.
- NEMA4X rated.
- Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
- Rated for Class 1, Division 2, Groups A, B, C, and D.
Options
- TP: Tamper-proof hardware helps discourage unauthorized access to the unit.
Need a Custom Configuration?
Our team can help you specify the perfect configuration for your project. Contact us for custom options or integration assistance.
